Products Pulse laser cleaning machine

Pulse laser cleaning machine

Get a free quote

It is a new generation of surface cleaning and high-tech products. It is easy to install, operate and automate. When the machine is powered up and on, you don't need to add any chemicals, dust, water or media to clean it. This handheld laser rust remover can not only remove surface resin, stains, grease, dirt, coatings and more. , and can also focus automatically.

1. Non-contact cleaning, does not damage the parts themselves;

2. The laser cleaning head is lightweight and can be operated by hand for a long time;

3. No chemical cleaning solution, no consumables, safe and environmentally friendly;

4. The operation is simple, it can be used immediately after power on, and it can be hand-held or cooperated with a manipulator to realize automatic cleaning.



Video

Technical Parameter

Pulsed laser power100W 200W 300W 500W Optional
Continuous power1000W 1500W 2000W 3000W Optional
Laser sourceRaycus JPT IPG Max
Scanning range10-80 mm
Expected focal length160 mm /210 mm
Fibre length5 meters /10 meters
Cooling typewater-cooling
Input power220V 50/60Hz
Power800W
Dimension1100*1000*800 mm
Weight185 kg


Application

This handheld laser rust remover is widely used in mold industry, automobile manufacturing, shipbuilding industry, food processing, sewage treatment, rubber tires, petrochemical industry and other industries.
